IoT Weighbridge 30ton-100ton
IoT weighbridge = weighbridge + sensor + network module + cloud platform + mobile phone / computer management backend
Automatic data upload, permanent storage, non-tamperable
Support for remote viewing, remote reconciliation, remote fault diagnosis
IoT Weighbridge Product Details
Introduction
The IoT Weighbridge （www.fjfangda.com）is a revolutionary product that combines the power of Internet of Things (IoT) technology with traditional weighbridge solutions. This innovative system offers a wide range of benefits for businesses in various industries, including improved efficiency, accuracy, and data management.
Fujian Fangda IoT Ground Scale Standard Parameter Table | |
Item | Specification |
Max Capacity | 60t / 80t / 100t / 120t / 150t (Optional) |
Accuracy Grade | OIML R60 Class C3/C6 (Legal for Trade) |
Weighing Division | 1kg / 2kg / 5kg / 10kg (Optional) |
Load Cell | Digital shear beam/column type, 20t-50t, IP68 protection, support IoT data transmission |
Weighing Indicator | IoT intelligent type, HD LED/LCD display, support remote calibration and data synchronization |
IoT Module | Support 4G/5G/WiFi/Ethernet, compatible with Modbus and MQTT protocols |
Scale Body Material | Q355B low-alloy high-strength steel, optional 304 stainless steel (anti-corrosion model) |
Protection Level | Scale body IP67, indicator IP54, load cell IP68 |
IoT Functions | Remote monitoring, real-time data upload, abnormal alarm, historical data query, cloud management, mobile APP viewing |
Working Temperature | -30℃～+70℃ (Wide temperature compensation, suitable for extreme environments) |
Communication Interface | RS232/RS485/Ethernet/4G/5G/WiFi |
Application Scenario） | Logistics parks, mines, quarries, ports, agricultural product purchasing stations and other scenarios requiring remote management |
FAQ 1: Is the FangDa IoT Weighbridge suitable for mining and quarrying in Africa?
Yes. The FangDa IoT Weighbridge (30–100 ton capacity, up to 150 tons customizable) is built for African mines and quarries. It delivers OIML Class C3/C6 accuracy, IP68 digital load cells, Q355B steel construction, and reliable operation from -30°C to +70°C. IoT features provide real-time cloud monitoring via 4G/5G.
FAQ 2: How does the FangDa IoT Weighbridge benefit logistics, ports, and transport in Africa?
It transforms a standard truck scale into a smart IoT system with automatic real-time data upload to the cloud for tamper-proof records. African logistics and port operators get remote access, mobile alerts, and ERP integration via 4G/5G or Wi-Fi. Ideal for fast compliance, billing, and overload prevention.
Engineered for harsh conditions with IP67/IP68 protection, Q355B steel (or optional 304 stainless), and full temperature compensation (-30°C to +70°C). Remote IoT calibration, data access, and instant alarms reduce downtime in remote areas. Perfect for mining, ports, and agricultural stations.
Key Features
- Real - time Monitoring: The IoT weighbridge allows for real - time monitoring of weights. You can access the weight data remotely via a web - based or mobile application, enabling you to keep track of transactions and operations at any time and from anywhere.
- High Accuracy: With advanced load cell technology, the weighbridge provides highly accurate weight measurements. This ensures that your business can rely on precise data for inventory management, shipping, and billing purposes.
- Data Logging and Analysis: All weight data is automatically logged and stored in a secure database. You can analyze this data to identify trends, optimize operations, and make informed business decisions.
- Connectivity: The weighbridge is equipped with various communication interfaces, such as Wi - Fi, Ethernet, and cellular networks. This enables seamless integration with other systems, such as enterprise resource planning (ERP) software, for a more streamlined workflow.
- Alerts and Notifications: Set up custom alerts and notifications based on specific weight thresholds or events. This helps you stay informed about critical situations and take immediate action.
Applications
- Logistics and Transportation: In the logistics industry, the IoT weighbridge helps in accurately measuring the weight of trucks, trailers, and cargo. This ensures compliance with weight regulations and prevents overloading, which can lead to safety hazards and costly fines.
- Manufacturing: Manufacturers can use the weighbridge to monitor the weight of raw materials and finished products. This helps in inventory management, quality control, and production planning.
Mining and Quarrying: In the mining and quarrying sectors, the weighbridge is used to measure the weight of minerals, aggregates, and other materials. This data is crucial for production reporting, invoicing, and resource management.
Installation and Maintenance
The IoT weighbridge is designed for easy installation. Our team of experts can install the weighbridge at your site and ensure that it is properly calibrated and configured. Regular maintenance is also provided to keep the weighbridge in optimal working condition.
Conclusion
The IoT Weighbridge is a game - changer for businesses that require accurate weight measurements and efficient data management. With its advanced features, wide range of applications, and reliable performance, it is the ideal solution for modern businesses looking to enhance their operations and competitiveness.
